    Rotary Joint


    Home - Products















    925-40A Rotary Joint


    Model：925-40A

      Outer pipe：flange connection

      Feature：Concave spherical seal;
Standardcarbon graphite sealing technology;
External seal structure design;
Precision cast iron shell;
Split type design;
Automatic centering;
Preventive maintenance design with sealing abrasion scale line;
Strong deflection adaptability;
Applicable to high-speed equipment operation.



      Technical Parameter：






				Media


				Steam






				Max.Temperature


				≤235 ℃






				Max.Pressure


				≤2.0 MPa






				Max.Speed


				≤600 rpm









     Product consultation Back to list


    Sales Service Hotline：


    0595-8686 1188
























				Model


				A


				B


				I


				O


				d1


				C1


				D1


				E1


				E2


				C2


				D2


				 F1


				S1


				L1


				L2


				L3


				L4


				L5


				L6


				n1-ΦN1


				n2-ΦN2






				40A


				60


				21


				Rc1-1/4"


				Rc1"


				47.5


				100


				9


				120


				205


				228


				5


				238


				30


				38


				151


				203


				219


				242


				38


				6-Φ17


				6-Φ11.5








	Except for the above product specifications.our company's product can also be customized according to the user's requirements;Specifications are subject to change without notice.
